Working logic and functions:After installation, the device enters into normal working state after the yellow and blue lights are always on.
Working logic: The device does not sleep in the state of motion, uploads position data every 20 seconds, enter into sleep mode after 5 minutes of rest, it only transmits heartbeat data after sleeping, if any vibration is detected during the stationary period, the device re-clocks for 5 minutes to sleep.
Vibration alarm: After the fortification, vibration will trigger the vibration alarm, and after the vibration alarm is triggered,
it needs to be static for 5 minutes before the alarm can be triggered again.
Power failure alarm: After the device is connected to the power supply, the device will judge the access to the power supply, and when the device is disconnected from the power supply for more than 3 seconds, the power failure alarm will be triggered and upload to the server.
Over-speed alarm: set the over-speed alarm threshold, when the speed exceeds the value, will trigger the over-speed alarm, and upload to the server.
# Support the function of cutting off oil/electricity of the vehicles, stop engine remotely.
# Support Geo-fence, users can set virtual electronic fence through the platform/APP, and when the device enters or exits the fence, it can be recognized by the platform and issue an alarm.
# Alarm SMS/phone call can be sent to the admin number in the event of an alarm, and the alarm will be uploaded to the platform at the same time.
# We adopted industrial-grade high-stability communication module from well-known manufacturers, built-in LTE high-sensitivity antenna, supports TCP/IP data transmission, and supports domain name/IP address to connect to the server.
# Built-in large-capacity memory chip, support data storage when in offline state, supplementary transmission of blind zone data; When the vehicle is in a place where the wireless signal is weak or the interference is serious, the device will store the data of the vehicle in FLASH temporarily, and when the wireless signal returns to normal, it can transmit these data, won’t miss any data.
# Built-in 3-axis acceleration sensor, integrated with accurate acceleration algorithm, real-time acquisition of vehicle data and other vehicle condition judgment.
# High-sensitivity GPS/BDS dual-star positioning module, anti-interference ceramic antenna, to achieve more stable signal
searching, support AGPS fast positioning tracking, synchronous timing.
# Low-power energy-saving mode, accurate judgment of car ignition and flame-out status, intelligent sleep and wake-up mechanism, can reduce the average power consumption of the entire system.
# OTA Support online remote upgrade and remote configuration of product parameters.
