Communication: | Cellular | Type: | Mini, Wireless, Magnetic |
---|---|---|---|
Network: | GSM, GPS, 4G, 2g, 2g Gsm, 4G CAT1 And 2G Networks | Battery: | 4200mAh, 4200mAh |
Placement: | Portable, Windshield, Dashboard | Positioning Mode: | GSM, GPS, GPRS, AGPS, Beidou, Power Saving Mode |
Track View: | PC, IOS APP, SMS Coordinate, Android APP | Battery Life (Hour): | >96H |
Function: | Waterproof, ANTI-SHOCK, Street View, Wheel Path Playback, Real-time Tracking | Data Storage: | Cloud Storage |
Warranty: | 12 Months | Use: | Motorcycle, Automotive, HAND HELD, Gps Tracker |
Button Battery: | NO | Connection: | 3G/4G Sim Card |
Fixed Method: | Magnetic Fixation | Power Source: | Battery Powered |
View Angle: | 360° Bird View | Gps Feature: | Remote Control |
Application: | Vehicle/motorcycle/person | Color: | Black |
Size: | 73.5mm * 42.8mm * 31.2mm | Weight: | 120g |
SIM Card Type: | Micro Sim Card | Usage: | For Tracking |
Battery Type: | NdFeB Permanent Magnet |
Work Voltage | DC 2.5V – 3.6V |
Work Current | 3V/Average 75MA |
Sleep Current | 3V/Lower than 3uA |
Built-in Battery Capacity | 4200mAh (3.7V Lithium manganese battery) |
Work Temp | -20℃ - 75℃ |
Work Humidity | 10%-85% RH Non-condensing |
4G Frequency Bands | LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28/B66 2G: 850/900/1800/1900MHz |
Sensitivity (tracking) | -162dBm |
TTFF (open sky) | Cold Start: average 32S Hot Start: average 1S |
Dimension | 73.5mm * 42.8mm * 31.2mm |
Unit Weight | 120g |
Suitable for | Insurance industry, enterprise fleet industry, car manufacturers / 4S shops, individual users, electric new energy field, passenger vehicles, taxis, leased vehicles, person, asset, container, cold chain vehicles, etc. |
